22.5*8.25

Time：2016-12-26 13:58 Author:admin Click:

forged aluminum wheel 22.5*8.25

lighter weight
fuel economy
higher loading capacity

SIZE	Part No.	Inset(mm)	outset(mm)	PCD HOLES	P.C.D (mm)	Stud (mm)	C.B (mm)	MAX LOAD	MAX LOAD	WEIGHT (kg)
22.5*8.25	T001208526A	144.5	168.7	10	285.75	26.75	220.1	4000KG	8800LBS	24.93
22.5*8.25	T004813526B	145	169	10	335	26	281.1	3650KG	8040LBS	24.73
22.5*8.25	T208218532A	134.5	168.5	10	285.75	32.5R22	221.1	3360KG	7400LBS	24.15
22.5*8.25	T015217532A	145	169	8	275	32.5	221.1	3650KG	8040LBS	26.53
22.5*8.25	T016813532A	144.5	168.5	10	335	32.5	281.1	3800KG	8370LBS	23.00
22.5*8.25	T023208526A	144.5	168.5	10	285.75	26.75	220.1	3650KG	8040LBS	23.88
22.5*8.25	T024813526A	145	169	10	335	26.75	281.1	3650KG	8040LBS	24.50
22.5*8.25	T231218532B	144	168	10	285.75	32.5R22	221.1	3360KG	7400LBS	23.73
22.5*8.25	T032813526A	145	169	10	335	26.75	281.1	3650KG	8040LBS	23.8
22.5*8.25	T033813532A	143	168	10	335	32.5	281.1	3650KG	8040LBS	25.8
22.5*8.25	T035813526A	143	168	10	335	26.75	281.1	3650KG	8040LBS	24.54
22.5*8.25	T037813526B	143	167	10	335	26	281.1	3650KG	8040LBS	24.80
22.5*8.25	T038218532B	143.5	167	8	285	32.5R22	221.2	3360KG	7400LBS	24.40
22.5*8.25	T046813532A	143	168	10	335	32.5	281.1	3650KG	8040LBS	25.8
22.5*8.25	T050218532A	143.5	168.5	10	285.75	32.5R22	221.1	3360KG	7400LBS	24.15
22.5*8.25	T051218532A	143.5	168.5	10	285.75	32.5R22	221.1	3360KG	7400LBS	24.15
22.5*8.25	T056813532A	144.5	167.5	10	335	32.5	281.1	3650KG	8040LBS	24.31
22.5*8.25	T059218532B	143.5	166.5	10	285.75	32.5R22	221.1	3650KG	8040LBS	24.35
22.5*8.25	T062813526B	143	166	10	335	26	281.1	3650KG	8040LBS	25.54
22.5*8.25	T063208526B	143.5	168.5	10	285.75	26	220.1	3360KG	7400LBS	23.80
22.5*8.25	T064813526A	143	168	10	335	26.75	281.1	3650KG	8040LBS	24.91
22.5*8.25	T067218532B	143	166	8	285	32.5R22	221.1	3360KG	7400LBS	27.50
22.5*8.25	T069813526B	145	166	10	335	26	281.1	3650KG	8040LBS	22.90
22.5*8.25	T070208526B	147	168	10	285.75	26	220.1	3360KG	7400LBS	21.50
22.5*8.25	T071218532B	143.5	168.5	10	285.75	32.5R22	221.1	3650KG	8080LBS	23.50
22.5*8.25	T073813526B	145	166	10	335	26	281.1	3650KG	8040LBS	22.90
22.5*8.25	T081208526B	143.5	168.5	10	285.75	26	220.1	3859KG	8500LBS	25.00
