  English > Products > Wheel products > Forged Aluminum wheel >
22.5*7.5
Time:2016-12-26 15:11  Author:admin Click:



SIZE Part No. Inset(mm)  outset(mm) PCD HOLES P.C.D  (mm) Stud (mm)  C.B (mm) MAX LOAD MAX LOAD WEIGHT (kg)
22.5*7.5 T003813532A 138 162 10 335 32.5 281.1 3550KG 7800LBS 22.20
22.5*7.5 T009218532B 138 162 8 285 32.5R22 221.1 3565KG 7800LBS 24.10
22.5*7.5 T040813532A 138 162 10 335 32.5 281.2 3550KG 7800LBS 22.2
22.5*7.5 T041218532C 138 162 8 285 32.5R22-45.8 221.2 3550KG 7800LBS 24.1
22.5*7.5 T065208526B 64 86 10 285.75 26 120.6 2270KG 5000LBS 20.71
22.5*7.5 T072813526B 138 160 10 335 26 281.1 3550KG 7800LBS
22.5*7.5 T083217526B 140 162 8 275 26 221.1 3452KG 7800LBS 25.50
